Damping Motor Wheel Robot Drive Wheels 2000kg Load Driving Platform

Specification

Description

The steering wheel is an integrated mechanical structure integrating drive motor, steering motor, planetary reducer, etc. It integrates product, walking, traction and steering functions, and can load and tow heavier goods. It can quickly deploy AGVs, mobile robots, etc. Perfectly meet the application requirements of AGV.

Therefore, steering wheel drive is the development direction of AGV applications. Compared with the traditional AGV trolley differential speed control method, the steering wheel has high integration, strong adaptability, higher precision and faster response when used with the servo system.

Dozens of steering wheels have been developed to be applicable to different industrial fields. Because of different customer needs and use environments, we also provide customized drive wheels.

(Such as installation height, wheel surface material, gear, speed, encoder, etc.)

Advantage

- The steering wheel series can carry 100KG-10000KG by single wheel.

- Choose high-power drive motors and types according to customer requirements.

- A variety of speed ratios can be selected, allowing small power to make large loads.

- Low installation height, as low as 130mm

Features

Small size: adopts integrated design, small size and light weight;

Simple operation: integrated automatic centering function;

Strong adaptability: In response to the mobile requirements of the machine, the core components are equipped with a shockproof system, which effectively prevents damage to the core components of the machine due to accidental impacts during the transportation and use of the equipment;

Various installation forms: horizontal and vertical

Multiple choices: AC or DC power supply;

Drive and steering integrated drive wheel products

Guangzhou Wisdom Wheel Science Technology Ltd. relies on technological innovation for development, and continues to provide users with satisfactory high-tech products. According to application needs, it has successfully developed a series of AGV steering wheels with different installation heights such as 400, 260, 230, 200, 170, 160, and 130. drive assembly, the load capacity of a single steering wheel ranges from 500kg to 10 tons, the traction force ranges from 200Kg to 10 tons, and the multi-steering wheel combination has a heaviest traction force of 100 tons.

The KIVA power system has also been affirmed by a large number of users; At the same time, the company is also unique in the field of heavy-duty handling, heavy-duty unmanned handling flatbed trucks, omnidirectional forklifts, and special assembly AGVs in special industries. AGV products have been widely used in many fields such as automobiles, metallurgy, chemicals, electronics, pharmaceuticals, tobacco, and military industries.

In the process of development, the company continuously communicates and cooperates with many domestic scientific research institutions, designs and produces, It already has a pivotal position in the automated logistics industry, leading the development of AGV-driven.

Our aim is to create value for customers with first-class product quality and superb technical service!
