    AC Motor Drive Vertical Caster AGV Mecanum Wheel 1000kg ZL-335

    Ask Lasest Price
    Brand Name : ZHLUN
    Supply Ability : 1000 Pieces per Month
    Price : Negotiable
    Model Number : ZL-335
    Payment Terms : L/C, T/T, Western Union
    Delivery Time : 25 days
    • Product Details
    • Company Profile

    AC Motor Drive Vertical Caster AGV Mecanum Wheel 1000kg ZL-335


    AC AGV Motor Drive Wheel ZL-335 Vertical Caster Wheel For AGV Industry


    Description


    The steering wheel is an integrated mechanical structure integrating drive motor, steering motor, planetary reducer, etc. It integrates product, walking, traction and steering functions, and can load and tow heavier goods. It can quickly deploy AGVs, mobile robots, etc. Perfectly meet the application requirements of AGV.

    Therefore, steering wheel drive is the development direction of AGV applications. Compared with the traditional AGV trolley differential speed control method, the steering wheel has high integration, strong adaptability, higher precision and faster response when used with the servo system.


    Dozens of steering wheels have been developed to be applicable to different industrial fields. Because of different customer needs and use environments, we also provide customized drive wheels.

    (Such as installation height, wheel surface material, gear, speed, encoder, etc.)


    AC Motor Drive Vertical Caster AGV Mecanum Wheel 1000kg ZL-335


    Specification


    ModelZL- 335
    Gear boxLevel 2 Stage gear
    Speed ratioI7-120
    Wheel diametermm180
    Speedm/min20-200
    Maximun loadKG1000
    Temperature- 10 to + 55
    WeightKG30
    Traction motorServo / Brushless
    Rate powerW200 - 2000
    Rate voltageV

    DC24-48V / AC220 above

    Rate speedrpm3000 ( customizable )
    Rate torqueN.m0.64 - 6.37
    Steering motorServo / Brushless
    Rate powerW200 - 750
    Rate voltageVDC24-48V / AC220 above
    Rate speedrpm3000 ( customizable )
    Rate torqueN.m0.32 - 1.39
    Reducer speed ratioI35 - 120
    Ranger± 120°
    Angle limitNPN / PNP
    SensorOptional

    AC Motor Drive Vertical Caster AGV Mecanum Wheel 1000kg ZL-335

    Advantage


    - The steering wheel series can carry 100KG-10000KG by single wheel.

    - Choose high-power drive motors and types according to customer requirements.

    - A variety of speed ratios can be selected, allowing small power to make large loads.

    - Low installation height, as low as 130mm


    Features


    Small size: adopts integrated design, small size and light weight;

    Simple operation: integrated automatic centering function;

    Strong adaptability: In response to the mobile requirements of the machine, the core components are equipped with a shockproof system, which effectively prevents damage to the core components of the machine due to accidental impacts during the transportation and use of the equipment;

    Various installation forms: horizontal and vertical

    Multiple choices: AC or DC power supply;

    Drive and steering integrated drive wheel products

    Selection the motor type and encoder type according to the project requirements.

    Multiple speed ratio choices, let small power do large load.

    AC Motor Drive Vertical Caster AGV Mecanum Wheel 1000kg ZL-335

    Key advantage


    1. Double support structure, running smoothly and uniform force.

    2. Multi-stage planetary reducer, high transmission efficiency and quieter.

    3. Compact structure and high integration, make the control more convenient.

    4. The wheel surface is made of composite polyurethane, which has high friction and strong grip.
