3000KG Motor Rubber Double Wheel Differential Drive Wheel Apply For
Factory Agv
The driving wheels of the AGV trolley are coated with polyurethane,
which can be customized according to the required load capacity of
the AGV trolleys of various enterprises. Under high load, the
polyurethane coated wheels have greater wear resistance to meet the
needs of enterprises. Polyurethane-coated AGV drive wheels have
various characteristics such as oil resistance, ozone resistance,
aging resistance, and radiation resistance, and support special
customization by enterprises.
| ZL-B543 Drive Wheel Parameter Table |
| Item | Name | Unit | Value |
| 1 | Installation height | mm | 543 |
| 2 | Wheel diameter | mm | 300*300 |
| 3 | Speed | m/min | 60 |
| 4 | Speed ratio | / | 1:50 |
| 5 | Maximum load | KG | 2000 |
| 6 | Traction motor | W | 3000 |
| 7 | Steering motor | W | 400 |
| 8 | Output torque | N.m | 1200 |
| 10 | Weight | KG | 50 |
Our steering wheels consist of extremely short drive wheel units,
integrated planetary gearboxes and bearings. Perfectly integrate
motors and controllers to form a compact control system, which
greatly simplifies the development and optimization of
self-propelled systems, such as service robots or AGVs.
The drive wheels are available in different diameters and mounting
flanges. space saving design Can withstand high radial and axial
loads Different wheel diameters are available Can be widely matched
with various motors, brakes and encoders Wheel drives can be
ordered with or without mounting brackets. For mass production,
Nanotec also offers compact tires made of special composite
materials.
Used in many industries, these wheels provide extreme life and
durability for repetitive robotic or stacking operations. We can
custom-fit your AGV equipment with wheels that will perform. The
urethanes can be custom formulated to the exact hardness you need.
