    Heavy Duty 48V 2KW Horizontal Servo Motor Wheel AGV Drive Wheels

    Ask Lasest Price
    Brand Name : ZHLUN
    Supply Ability : 1000 Pieces per Month
    Price : Negotiable
    Model Number : ZL-490
    Payment Terms : L/C, T/T
    Delivery Time : 25 days
    • Product Details
    • Company Profile

    Heavy Duty 48V 2KW Horizontal Servo Motor Wheel AGV Drive Wheels


    Heavy Duty 48V 2KW AC Motor Drive Wheel Agv Horizontal Wheels


    Spcification


    ModelZL-490
    Gear boxLevel 2 Stage gear
    Speed ratioI7-120
    Wheel diametermm400
    Speedm/min20-200
    Maximun loadKG2000
    Temperature- 10 to + 55
    WeightKG75
    Traction motorServo / Brushless
    Rate powerW1000 - 2000
    Rate voltageVDC24-48V / AC220 above
    Rate speedrpm3000 ( customizable )
    Rate torqueN.m3.18 - 9.68
    Steering motorServo / Brushless
    Rate powerW750 - 1000
    Rate voltageVDC24-48V / AC220 above
    Rate speedrpm3000 ( customizable )
    Rate torqueN.m2.39 - 3.18
    Reducer speed ratioI35 - 120
    Ranger± 120°
    Angle limitNPN / PNP
    SensorOptional

    Description


    Suitable for electric transportation vehicles

    Optional motor type: AC/BLDC/Servo
    Voltage can be customized
    Optional multiple well-known sensors (absolute value, incremental, etc.)
    Various installation heights (145mm-490mm), small size, large bearing capacity (100kg-10T) , and large traction (200W-3kw)
    Multiple speed ratio choices (1:7-1:96)

    Features


    Small size: adopts integrated design, small size and light weight;

    Simple operation: integrated automatic centering function;

    Strong adaptability: In response to the mobile requirements of the machine, the core components are equipped with a shockproof system, which effectively prevents damage to the core components of the machine due to accidental impacts during the transportation and use of the equipment;

    Various installation forms: horizontal and vertical

    Multiple choices: AC or DC power supply.
